Video Compression

H.264

Video System

NTSC / PAL

Operation System

Linux Based

Video Input / Output

BNC 8-Channel Input / 1-Channel Output

Other Video Output

VGA

Audio Input / Output

RCA 4-Channel Input / BNC 1-Channel Output

Display Frame Rate

NTSC: 240 fps @ D1 / PAL: 200 fps @ D1

Display Resolution

NTSC: D1 (704 x 480)/ PAL: D1 (704 x 576)

Recording Frame Rate

NTSC: 240 fps @ CIF / PAL: 200 fps @ CIF

Record Resolution

Selectable: NTSC: D1(704 x 480); HD1(704 x 240); CIF (352 x 240) / PAL: D1(704 x 576); HD1(704 x 288); CIF (352 x 288)

Record Mode

Continuous / Time Schedule / Motion Detection

Network Function

Support Live View with IE & Mobile Phone

Net Protocol

TCP/IP, PPPoE, DHCP and DDNS

Remote Access

LAN or Internet Browsing

PTZ Control

RS-485

HDD Interface

SATA, Support between 250GB and 2TB

USB

USB Backup/USB 2.0

Remote Control

IR Remote Control

Dimension

12.8 "(W) x 10.4" (D) x 3.9"(H)
