VoIP VM-S2024PEG-C - 24-port 10/100/1000M PoE Switch, 16 10/100/1000M RJ45 ports,managed

Chargement...

-38%

24-port 10/100/1000M PoE Switch, 16 10/100/1000M RJ45 ports,managed FR-S2024PEG-C

VM-S1024PEG-C 24 ports 10/100 / 1000M Switch PoE fournit la connexion réseau sans coupure.Ne pas utiliser sur plus de 12 caméras.

Ce produit n'est plus proposé à la vente

Disponibilité : Obsolète (Fin de vie)

Evaluation :

Evaluer ce produit.

Description
Téléchargements
Avis des clients

FICHE TECHNIQUE

Descriptions du Produit

VM-S1024PEG-C 24-port 10/100/1000M POE Switch provides the seamless network connection. It integrates 10/100/1000Mbps Ethernet network capabilities. These POE ports can automatically detect and supply power with those IEEE 802.3at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.

Features

Complies with IEEE802.3, IEEE 802.3u, IEEE 802.3ab standards

24 x 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX

Supports PoE power up to 30W for each PoE port

Supports ALL power up to 260W

Supports PoE IEEE802.3at compliant PDs

Supports IEEE802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode

16K entry MAC address table of the VM-S2024PEG with auto-learning and auto-aging

LED indicators for monitoring power, link, activity and speed

Internal power adapter supply

SPECIFICATIONS

Model		VM-S1024PEG-C
Chipset		RTL8389L + RTL8218+RTL8231
Standards		IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3at, IEEE 802.3af
Network Media (Cable)		10BASE-T: UTP category 5 cable (maximum 100m) 100BASE-T: UTP category 5 cable (maximum 100m) 1000Base-T: UTP category 5, 5e cable (maximum 100m)
Number of Ports		24 x 10/100/1000Mbps Auto-Negotiation ports
LED indicators	Port	Link/Act
	POE	POE
	Other	Power
Transfer Method		Store-and-Forward
MAC Address Table		16K
Switching Capacity		48Gbps
Frame Filtering and Forward Rate		10Mbps: 14880pps 100Mbps: 148800pps 1000Mbps: 1488000pps
Dimensions (L × W × H)		44220844 mm
Environment		Operating Temperature: 0℃~40℃ Storage Temperature: -10℃~70℃ Operating Humidity: 10%~90% non-condensing Storage humidity: 5%~90% non-condensing
